SynGAP抗体

ICC/IF analysis of PC-12 cells using GTX23344 SynGAP antibody. Panel e is a no primary antibody control.
Green : Primary antibody
Blue : Nuclei
Red : Actin
Fixation : 4% paraformaldehyde
Permeabilization : 0.1% Triton X-100 for 10 minute
Dilution : 2 μg/ml in 0.1% BSA and incubated for 3 hours at room temperature

IHC-P analysis of human heart tissue using GTX23344 SynGAP antibody.
Right : Primary antibody
Left : Negative control without primary antibody
Antigen retrieval : 10mM sodium citrate (pH 6.0), microwaved for 8-15 min
Dilution : 1:100

ICC/IF analysis of rat hippocampal neurons using GTX23344 SynGAP antibody.

ICC/IF analysis of rat hippocampal neurons using GTX23344 SynGAP antibody.
