TLR3抗体 [HL2314]

TLR3 antibody [HL2314] detects TLR3 protein at cytoplasm by immunohistochemical analysis.
Sample: Paraffin-embedded dog brain.
TLR3 stained by TLR3 antibody [HL2314] (GTX638477) diluted at 1:100.
Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

Various whole cell extracts (30 μg) were separated by 7.5% SDS-PAGE, and the membrane was blotted with TLR3 antibody [HL2314] (GTX638477) diluted at 1:1000. The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody, and the signal was developed with Trident femto Western HRP Substrate. Corresponding RNA expression data for the same cell lines are based on Human Protein Atlas program.

Various whole cell extracts (30 μg) were separated by 7.5% SDS-PAGE, and the membrane was blotted with TLR3 antibody [HL2314] (GTX638477) diluted at 1:1000. The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody.

TLR3 antibody [HL2314] detects TLR3 protein at cytoplasm by immunohistochemical analysis.
Sample: Paraffin-embedded mouse intestine.
TLR3 stained by TLR3 antibody [HL2314] (GTX638477) diluted at 1:100.
Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

TLR3 antibody [HL2314] detects TLR3 protein by immunohistochemical analysis.
Sample: Paraffin-embedded rat tissues.
TLR3 stained by TLR3 antibody [HL2314] (GTX638477) diluted at 1:100.
Antigen Retrieval: Citrate buffer, pH 6.0, 15 min
